AES Pedestal IP Intercom + Keypad (Stainless) | AES-PRAE-IP-PSK-US
$1,847.99
AES Pedestal IP Intercom + Keypad (Stainless) | AES-PRAE-IP-PSK-US
All stainless, marine-grade steel pedestal mount IP intercom. Modern white illuminated buttons. Panels available with and without Keypad. (*Pedestal with 4G antenna built-in available)
Includes
Speech panel
Antenna
Power supply
Install manual
Features
Long Range Antenna (2.4GHz) (up to 65 yards working range depending on router type and location)
Existing Wi-Fi Hub
Praetorian APP
Speak to your visitors from anywhere in the world.
Grant access remotely – Send a command to the gate motor via the app to open your gates etc.
Keypad Codes – 24-7 / Timed / Temporary (Optional)
No Touch Access – PROX Cards/ Tags – 24-7 / Timed / Temporary (Optional)
Voicemail – Visitors can leave a video message when unanswered.
Multi-User – Add up to 8 maximum devices per Intercom ID. (incl ADMIN user. 4 maximum for optimal performance.)
Connect via WiFi, LAN Cable, or 4G Access Point (Sold Separately) (Dualband WIFI. 2.4 & 5.8G wifi (IEEE 802.11a/b/g/n/ac)
The volume of the external speaker is adjustable at the call-point.
Super clear, 120° HD camera image.
Manufacturer’s Warranty Period
2 years
Technical Specifications
Front Panel:Â PB/PBK = Pedestal Surface Mount
Hood Cover (MOD, IMP(K), PED:Â Powder coated Aluminium
Mounting Housing (Backbox):Â Marine Grade Stainless Steel BS316
Mounting Type:Â Surface-Mounted with backlighting, Flush-mounted version sold separately
Call Button:Â Stainless-steel button with illuminated LED Ring
Weatherproof:Â IP55
Approvals:Â CE, FCC
Operating Temperature: -25 to +55°C / -13 to 131°F
Power Supply:Â 24V DC
Power Consumption:Â IP PCB w/Keypad & Prox |Â Standby = 80mA |Â Operating = 300mA
Solar Power:Â 45Watt Solar Panel (minimum) |Â 2x 12V 15AH Batteries connected in series to provide 24V output
Connectors: LAN (RJ45) – 2 x Bistable latching relay, max. 1-28V DC/AC, 1A, e.g. for magnetic door lock, External input for push to exit button, 24V DC input (+, -).
System Requirements:Â Mobile device: Newest iOS on iPhone/iPad, newest Android on Smartphone/Tablet Internet: High-Speed Landline Broadband Internet connection, DSL, cable or fiber optic, no SOCKS or proxy server. Min. suggested upload speed of 1.5mbps, Network: Ethernet Network, with DHCP / WIFI 2.4GHz/5.8GHz (with applicable antenna)
Recommended Installation Height:Â Camera lens should be at a min. height of145 cm (57 in). Before the installation please determine your optimal installation height.
Product Literature
AES Praetorian Guard Catalogue
AES Warranty Disclaimer
