Linear Indoor and Outdoor Flush-mount Weather Resistant Keypad | LIN-212w
$151.99
Linear Indoor and Outdoor Flush-mount Weather Resistant Keypad | LIN-212w
The 212w style single door access control keypad is designed to meet the indoor/outdoor flush mount needs of lighter volume access control environments. The w style features a sealed membrane keypad that allows the keys to be cleaned and resist moisture. There are three LEDs to indicate operation status and provide the user with visual PIN entry confirmation. The W-style keypad mounts to most standard single-gang electrical back boxes.
Features
120 users
Single-gang design
1 SPDT 2 amp relay and three 50mA negative voltage outputs
With 212 modes
Optional 293 relay board converts 3 voltage outputs to SPDT relays
Indoor/outdoor use
Technical Specifications
Dimensions: 2.75″ W x 4.50″ H x 1.13″ D
Dimensions including the 293 relay module: 2.75″ W x 4.50″ H x 1.675″ D
Operating voltage: 12-24 VAC/DC – auto adjusting
Current draw: 94 mA maximum (add 30 mA for each additional relay)
Functionality mode: 212, 232
Temperature tolerance: -20F to 130F
Order number: 211222
Product Literature
Linear 212w Instructions Manual
Access Code List Tracker
