SecuraKey eTag Contactless Smart Card Reader Mid-range Black | SKY-ET9-RO-W-MR
$145.99
SecuraKey eTag Contactless Smart Card Reader Mid-range Black | SKY-ET9-RO-W-MR
Secura Key’s new e*Tag® Midrange Reader creates a new product category of cost-effective extended read range products for the contactless smart card reader market. The e-Tag® Midrange Reader provides up to an 8” read range for about the same price as competing wall-switch readers.
Contactless Smart Card technology is ideally suited for access control, time and attendance, membership/loyalty programs, logical (PC) access, storage of biometric templates, parking, ePurse, and many other applications requiring secure and reliable read/write cards.
Features
ISO 15693 13.56 MHz Technology
Card Data Encrypted Using DES with Diversified Keys
SIA Standard Wiegand Output – Works with any Standard Access Control Panel
Epoxy Potted for Superior Weather Resistance
Single 2S or Dual 4S US J-Box mounting or European J-Box mounting
Industry Standard Wire Colors and Functions for Easy Upgrade
External LED and Buzzer Controls
Low Voltage and Low Current Draw
UL294, FCC, and CE Regulatory Approvals
High-performance 32-bit ARM Cortex microcontroller
Technical Specifications
Dimensions (L x W x H): 5.95” x 6.1” x 0.95” 15.1 x 15.5 x 2.41 cm
Mounting: US single or dual-gang box, European J-Box, wall, post
Weight: 15.4 oz (436.58 gm)
Material: Polycarbonate
Color: Black
Power Requirements: 100/200 mA avg/max. @ 5-14VDC
Bi-Color LED: Red and Green – Ground to Activate
Buzzer Control: Ground to Activate
Hold Line: Ground to Activate
Communications: Wiegand
Cable Required: Up to 500 ft., 5-10 conductor (depending on options used); 18-22 AWG Shielded
Environmental: Operating Temperature: 40° F to +158° F (40° C to +70° C) Relative Humidity: 0-100% Non-Condensing
Operating Frequency: 13.56 MHz
Reading Distance: ISO card up to 8” (20.32 cm) Key tag up to 5” (12.7 cm)
ISO Standard: 15693
Data Encryption: DES with diversified keys
Operating modes: Read-only card data
Compatible Cards: ETCI (ISO), ETST (key tag), ETAT (adhesive label)
Regulatory Approvals: UL/cUL294, Part 15 Class B FCC, CE Mark, Canada Radio
Warranty: These Secura Key products are warranted against defects in materials and workmanship for life. Secura Key will replace any Secura Key manufactured product that fails to perform as intended. This warranty does not include freight, taxes, duties, or installation expenses. See the price list for complete terms and conditions, the pricelist for complete terms and conditions.
Product Literature
SecuraKey ET9-RO-W-MR Installation Manual
SecuraKey ET9-RO-W-MR Datasheet
