Viking G5 – Solar ECU Big Dual Leaf | VIK-VA-ECUBMSNXSLR
$875.99
Viking G5 – Solar ECU Big Dual Leaf | VIK-VA-ECUBMSNXSLR
ECU Big Box Solar – Dual Controller
Features
UL 325 compliant
Two monitoring inputs w/ up to 4 devices per input
On board display
Built-in voltmeter
Lightning strike protection
12V Solar panel input
12V Battery charger
Solar panel switch
Battery switch
Sleep mode
Adaptive motor control
Adjustable speed control
Anti-tailgating feature
Built-in 3A solar charge regulator
Big box can hold a 35Ah battery
Enclosure
Aluminum construction
Powder coated
Post-mount options built-in
Pre-punched holes for conduit
Padlock latch
IP54-certified ingress protection
Manufacturer’s Warranty Period
2 years
Technical Specifications
Compatible Models: G5 Solar
Operating Voltage: 24VDC
Main Power Fuse: 4A Timed
Power Source: 12VDC
Accessory Power: 24VDC – 750mA
Power Consumption – Sleep: 19mA
Motor Current (Typical): 2.0A
Operating Temperature: -4°F (-20°C) to 160°F (71°C)
Dimensions Standard Box (L x D x H): 16.375 x 6.25 x 17.875 in
Dimensions Big Box (L x D x H): 18.75 x 8.125 x 18.2 in
Product Literature
Viking Limited Warranty Policy
